Biaxial Strain Gauges
2-Element 0/90º

SGD-2/350-XY11

Biaxial Strain Gauges2-Element 0/90º

^€221,07 SGD-2/350-XY11

PLACE ORDER

Conveniently Priced per Pack of 5
X-Y Pattern for Axial Strain
Very Flexible, Mechanically Strong
Small Bending Radius
Broad Temperature Range
Clear Alignment Marks
Affix with Cold or Hot Curing Adhesives

Strain Gages, Accessories and Instrumentation - View related products

Description

Click on this link if you need more information about Strain Gauge.

0/90º Stacked Tee gauge pattern for measuring axial strain.

For examples of actual strain gauge applications please see our Guide to strain gauge installations

For more in-depth application details and formulae see our guide on How to position strain gauges to monitor bending, axial, shear and torsional loads

We also have General information on strain gauge installation

If the delivery time shows 6 weeks or more, please call our Sales team, as most times we can ship in 2 WEEKS.

Place Order(Specify Model Number)

Part Number/Desc.

Qty

Description

Encapsulated with Ribbon Leads, Matched to Steel (PRICE PER PKG OF 5)

SGD-2/120-XY11

€198.73

Availability: 5 weeks

2 mm Grid, 120 Ohms, X-Y Pattern

SGD-2/350-XY11

€221.07

Availability: 5 weeks

2 mm Grid, 350 Ohms, X-Y Pattern

SGD-3/120-XY11

€191.13

Availability: 5 weeks

3 mm Grid, 120 Ohms, X-Y Pattern

SGD-3/350-XY11

€205.84

Availability: 5 weeks

3 mm Grid, 350 Ohms, X-Y Pattern

SGD-7/120-XY11

€258.58

Availability: 5 weeks

7 mm Grid, 120 Ohms, X-Y Pattern

SGD-7/350-XY11

€260.01

Availability: 5 weeks

7 mm Grid, 350 Ohms, X-Y Pattern

Encapsulated with Ribbon Leads, Matched to Aluminium (PRICE PER PKG OF 5)

SGD-2/120-XY13

€191.13

Availability: 5 weeks

2 mm Grid, 120 Ohms, X-Y Pattern

SGD-2/350-XY13

€221.07

Availability: 5 weeks

2 mm Grid, 350 Ohms, X-Y Pattern

SGD-3/120-XY13

€198.73

Availability: 5 weeks

3 mm Grid, 120 Ohms, X-Y Pattern

SGD-3/350-XY13

€205.84

Availability: 5 weeks

3 mm Grid, 350 Ohms, X-Y Pattern

SGD-7/120-XY13

€268.84

Availability: 5 weeks

7 mm Grid, 120 Ohms, X-Y Pattern

SGD-7/350-XY13

€268.84

Availability: 5 weeks

7 mm Grid, 350 Ohms, X-Y Pattern

Encapsulated with Solder Pads, Matched to Steel (PRICE PER PKG OF 5)

SGD-2/120-XY41

€174.72

Availability: 5 weeks

2 mm Grid, 120 Ohms, X-Y Pattern

SGD-2/350-XY41

€205.84

Availability: 5 weeks

2 mm Grid, 350 Ohms, X-Y Pattern

SGD-3/120-XY41

€177.48

Availability: 5 weeks

3 mm Grid, 120 Ohms, X-Y Pattern

SGD-3/350-XY41

€209.89

Availability: 5 weeks

3 mm Grid, 350 Ohms, X-Y Pattern

SGD-7/120-XY41

€225.26

Availability: 5 weeks

7 mm Grid, 120 Ohms, X-Y Pattern

SGD-7/350-XY41

€234.22

Availability: 5 weeks

7 mm Grid, 350 Ohms, X-Y Pattern

Encapsulated with Solder Pads, Matched to Aluminium (PRICE PER PKG OF 5)

SGD-2/120-XY43

€177.48

Availability: 5 weeks

2 mm Grid, 120 Ohms, X-Y Pattern

SGD-2/350-XY43

€199.06

Availability: 5 weeks

2 mm Grid, 350 Ohms, X-Y Pattern

SGD-3/120-XY43

€177.48

Availability: 5 weeks

3 mm Grid, 120 Ohms, X-Y Pattern

SGD-3/350-XY43

€188.15

Availability: 5 weeks

3 mm Grid, 350 Ohms, X-Y Pattern

SGD-7/120-XY43

€221.76

Availability: 1 week

7 mm Grid, 120 Ohms, X-Y Pattern

SGD-7/350-XY43

€254.85

Availability: 5 weeks

7 mm Grid, 350 Ohms, X-Y Pattern

† All amounts shown in EUR
Note: Packages of 5
