IP55 Steel Sloping Front Pushbutton Enclosures for 22mm & 30.5mm Pushbuttons

SCE-PBA Series Sloping Pushbutton Enclosures

 Currency
1 year warranty NEW! RoHS

SCE-PBA Series Sloping Pushbutton Enclosures : IP55 Steel Sloping Front Pushbutton Enclosures for 22mm & 30.5mm Pushbuttons

Click to enlarge image


EUR 106,00  SCE-6PBA
Made from 1.9 mm Thick Carbon Steel
IP55 Rating for Water and Dust Protection
Continuously Welded Seams
Captivated Cover Screws Thread Into Sealed Wells
4-Way Pushbutton Holes Accept All Brands of Oil-Tight Pushbuttons, Switches and Pilot Lights
Oil-Resistant Gasket

View related products - NEMA Electrical Enclosures

Click to scroll below to order ANSI Specs Related Items

Application
Designed to offer protection for all standard brands of oil-tight pushbuttons, switches, and pilot lights where slanted surfaces are desired. It offers protection from dust, dirt, oil and water.

Finish
ANSI-61 grey powder coating inside and out over phosphatized surfaces.

Industry Standards
NEMA Type 12 & Type 13
UL Listed Type 12
CSA Type 12
IEC 60529 IP 55
SCE_PBA Series Dimension Diagrams


To Order (Specify Model Number)
     Part Number     Availability   Price   Description   RoHS   Qty
 IP55 Front Sloping Pushbutton Enclosures for 30.5mm Pushbuttons
 SCE-1PBA   1 Week   EUR 55,00    1 PB enclosure, Height=3.50 Width=3.25 Depth(C)=4.84 Depth(D)=3.53 RoHS compliant
 SCE-2PBA   1 Week   EUR 64,00    2 PB enclosure, Height=3.50 Width=5.50 Depth(C)=4.84 Depth(D)=3.53 RoHS compliant
 SCE-3PBA   2 Weeks   EUR 72,00    3 PB enclosure, Height=3.50 Width=7.75 Depth(C)=4.84 Depth(D)=3.53 RoHS compliant
 SCE-4PBA   2 Weeks   EUR 82,00    4 PB enclosure (1x4), Height=3.50 Width=10.00 Depth(C)=4.84 Depth(D)=3.53 RoHS compliant
 SCE-4SPBA   2 Weeks   EUR 91,00    4 PB enclosure (2x2), Height=7.25 Width=6.25 Depth(C)=6.75 Depth(D)=6.78 RoHS compliant
 SCE-6PBA   2 Weeks   EUR 106,00    6 PB enclosure (2x3), Height=7.25 Width=8.50 Depth(C)=6.75 Depth(D)=6.78 RoHS compliant
 SCE-8PBA   1 Week   EUR 120,00    8 PB enclosure (2x4), Height=7.25 Width=10.75 Depth(C)=6.75 Depth(D)=6.78 RoHS compliant
 SCE-9PBA   1 Week   EUR 125,00    9 PB enclosure (3x3), Height=9.50 Width=8.50 Depth(C)=7.88 Depth(D)=8.73 RoHS compliant
 SCE-10PBA   2 Weeks   EUR 133,00    10 PB enclosure (2x5), Height=7.25 Width=13.00 Depth(C)=6.75 Depth(D)=6.78 RoHS compliant
 SCE-12PBA   2 Weeks   EUR 145,00    12 PB enclosure (2x6), Height=7.25 Width=15.25 Depth(C)=6.75 Depth(D)=6.78 RoHS compliant
 SCE-12SPBA   2 Weeks   EUR 139,00    12 PB enclosure (3x4), Height=11.75 Width=8.50 Depth(C)=9.00 Depth(D)=10.69 RoHS compliant
 SCE-16PBA   2 Weeks   EUR 155,00    16 PB enclosure (4x4), Height=11.75 Width=10.75 Depth(C)=9.00 Depth(D)=10.69 RoHS compliant
 IP55 Front Sloping Pushbutton Enclosures for 22mm Pushbuttons
 SCE-1PBAI   1 Week   EUR 55,00    1 PB enclosure, Height=3.50 Width=3.25 Depth(C)=4.84 Depth(D)=3.53 RoHS compliancy undetermined
 SCE-2PBAI   1 Week   EUR 64,00    2 PB enclosure, Height=3.50 Width=5.50 Depth(C)=4.84 Depth(D)=3.53 RoHS compliancy undetermined
 SCE-3PBAI   2 Weeks   EUR 72,00    3 PB enclosure, Height=3.50 Width=7.75 Depth(C)=4.84 Depth(D)=3.53 RoHS compliancy undetermined
 SCE-4PBAI   1 Week   EUR 82,00    4 PB enclosure (1x4), Height=3.50 Width=10.00 Depth(C)=4.84 Depth(D)=3.53 RoHS compliancy undetermined
 SCE-4SPBAI   2 Weeks   EUR 91,00    4 PB enclosure (2x2), Height=7.25 Width=6.25 Depth(C)=6.75 Depth(D)=6.78 RoHS compliancy undetermined
 SCE-6PBAI   2 Weeks   EUR 106,00    6 PB enclosure (2x3), Height=7.25 Width=8.50 Depth(C)=6.75 Depth(D)=6.78 RoHS compliancy undetermined
 SCE-8PBAI   2 Weeks   EUR 120,00    8 PB enclosure (2x4), Height=7.25 Width=10.75 Depth(C)=6.75 Depth(D)=6.78 RoHS compliancy undetermined
 SCE-9PBAI   2 Weeks   EUR 125,00    9 PB enclosure (3x3), Height=9.50 Width=8.50 Depth(C)=7.88 Depth(D)=8.73 RoHS compliancy undetermined
 SCE-10PBAI   1 Week   EUR 133,00    10 PB enclosure (2x5), Height=7.25 Width=13.00 Depth(C)=6.75 Depth(D)=6.78 RoHS compliancy undetermined
 SCE-12PBAI   2 Weeks   EUR 145,00    12 PB enclosure (2x6), Height=7.25 Width=15.25 Depth(C)=6.75 Depth(D)=6.78 RoHS compliancy undetermined
 SCE-12SPBAI   2 Weeks   EUR 139,00    12 PB enclosure (3x4), Height=11.75 Width=8.50 Depth(C)=9.00 Depth(D)=10.69 RoHS compliancy undetermined
 SCE-16PBAI   2 Weeks   EUR 155,00    16 PB enclosure (4x4), Height=11.75 Width=10.75 Depth(C)=9.00 Depth(D)=10.69 RoHS compliancy undetermined
 Base and Column Accessories
 SCE-18SBASE   2 Weeks   EUR 88,00    Pedestal Base 18.00 x 18.00 x 1.00 RoHS compliant
 SCE-24SBASE   2 Weeks   EUR 199,00    Pedestal Base 24.00 x 24.00 x 1.00 RoHS compliant
 SCE-44CCOL   2 Weeks   EUR 145,00    Straight Column 4.00 x 4.00 x 35.00 RoHS compliant
 SCE-44PBCOL   2 Weeks   EUR 172,00    Angled Column 4.00 x 4.00 x 35.00 RoHS compliant
 SCE-66CCOL   2 Weeks   EUR 217,00    Straight Column 6.00 x 6.00 x 35.00 RoHS compliant
 SCE-66PBCOL   2 Weeks   EUR 258,00    Angled Column 6.00 x 6.00 x 35.0 RoHS compliant
 OMPBD7-AHA1   1 Week   EUR 10,50    30mm to 22mm Adapter (mount 22mm PB's in 30mm holes), stainless steel RoHS compliancy undetermined



Ordering Example:
(1) SCE-1PBA  IP55 Angled Front Pushbutton Enclosure, EUR 55,00
