Temperature, Process, Strain, pH or ORP Meters with Optional Relays, Analog Outputs and Display Options - Discontinued

DP25 Series (SEE DP25B SERIES)

Temperature, Process, Strain, pH or ORP Meters with Optional Relays, Analog Outputs and Display Options | DP25 Series (SEE DP25B SERIES)

See All Models Below

PLACE ORDER
5 year warranty CE
  • Extended 5-Year Warranty at No Extra ChargeInputs
  • Strain Gage
  • Process (dc Voltage and Current)
  • Thermocouple
  • Dual Differential Thermocouple
  • RTD
  • Dual Differential RTD
  • Thermistor Options
  • Relay Output with Adjustable Deadband
  • Isolated or Non-Isolated Analog Output
  • Red or Green Display
  • Low Voltage Power Options

Description

This product has been discontinued. For a potential replacement, please see our Platinum Panel Meter Series.

Click on this link if you need more information about Panel Meters.

Panel Meters/Controllers The unparalleled accuracy of the OMEGA® DP25 signal conditioner is available in an economical series of panel meters/controllers. The OMEGA™ DP25 series of meter/controllers feature a four-digit, 14-segment display plus optional dual 6 amp SPDT relays (Single Pole Double Throw; Form C) and a choice of isolated or non-isolated analog output. The scalable 0-10 Vdc, 0-20 mA, or 4-20 mA analog output can be used for retransmission of the display value or as a proportional control output, as required. The microprocessor-based DP25 series includes instruments for process (dc voltage and current) strain gage, thermocouple, RTD, dual/differential thermocouple, dual/differential RTD, pH, orp, ac voltage and current.

For related books on Controller Theory and Applications, click here.
Place Order(Specify Model Number)
Part Number/Desc.
Qty
Description
DP25-RTD-DC10/32
Consult Sales
Availability:


Panel Meter, RTD Input,10 to 32 Vdc
DP25-RTD-GN
Consult Sales
Availability:


Panel Meter, RTD Input, Green Display
DP25-RTD-GN-A
Consult Sales
Availability:


Panel Meter, RTD Input, Green Display, Analog Output
DP25-RTD-GN-R
Consult Sales
Availability:


Panel Meter, RTD Input, Green Display, Relay Output
DP25-TC-230
Consult Sales
Availability:


Panel Meter, Thermocouple Input, 230 Vac
DP25-TC-AI-R-230
Consult Sales
Availability:


Panel Meter, Thermocouple Input, Isolated Analog Output, 230 Vac
DP25-TC-DC10/32-AR
Consult Sales
Availability:


Panel Meter, Thermocouple Input, 10 to 32 Vdc, Analog Output, Relay Output
DP25-TC-GN-DC10/32-AR
Consult Sales
Availability:


Panel Meter, Thermocouple Input, Green Display, 10 to 32 Vdc, Analog Output, Relay Output
DP25-TC-GN-DC10/32-AR
Consult Sales
Availability:


Panel Meter, Thermocouple Input, Green Display, 10 to 32 Vdc, Analog Output, Relay Output
DP25-TC-GN-DC26/56
Consult Sales
Availability:


Panel Meter, Thermocouple Input, Green Display, 26 to 56 Vdc
DP25-TH
Consult Sales
Availability:


Panel Meter, Thermistor Input
DP25-TH-A
Consult Sales
Availability:


Panel Meter, Thermistor Input, Analog Output
DP25-TH-A-DC10/32
Consult Sales
Availability:


Panel Meter, Thermistor Input, Analog Output, 10 to 32 Vdc
DP25-TH-AR
Consult Sales
Availability:


Panel Meter, Thermistor Input, Analog Output, Relay Output
DP25-TH-AR-DC10/32
Consult Sales
Availability:


Panel Meter, Thermistor Input, Analog Output, Analog Output, Relay Output, 10 to 32 Vdc
DP25-TH-AR-DC26/56
Consult Sales
Availability:


Panel Meter, Thermistor Input, Analog Output, Analog Output, Relay Output, 26 to 56 Vdc
DP25-TH-DC10/32
Consult Sales
Availability:


Panel Meter, Thermistor Input,10 to 32 Vdc
DP25-TH-DC26/56
Consult Sales
Availability:


Panel Meter, Thermistor Input, 26 to 56 Vdc
DP25-TH-GN-A
Consult Sales
Availability:


Panel Meter, Thermistor Input, Green Display, Analog Output
DP25-TH-R
Consult Sales
Availability:


Panel Meter, Thermistor Input, Relay Output
PHCN-37
€790.08
Availability: 7 weeks

pH with dual 6 A relays
ORCN-37
Consult Sales
Availability:


pH or ORP with Dual 6 A relays
OPCN-37
Consult Sales
Availability:


pH or ORP with Dual 6 A relays
† All amounts shown in EUR
 Note: Power Options are Not Field Installable


Part Number Builder

Build Your Part Number Below
Option Descriptions:


(1) Base Meter with 110 Vac Power select from:
DP25-E for Process Meter
DP25-S for Strain Input Meter
DP25-TC for Thermocouple Meter
DP25-RTD for RTD Meter
DP25-TH for Thermistor Meter
DP26-TC for Dual Differential Thermocouple Meter
DP26-RTD for Dual Differential RTD Meter

(2) Power Options select from:
Nothing(leave field blank) for Standard Unit with 115 Vac
-230 for 230 Vac
-DC10/32 for 10 to 32 Vdc
-DC26/56 for 26 to 56 Vdc

(3) Output Options select from:
Nothing(leave field blank) for Standard Unit without Outputs
-A for Non-Isolated Analog Output
-AI for Isolated Analog Output
-R for Dual 6 A Relays
-AR for Non-Isolated Analog Output with Dual 6 A Relays
-AI-R for Isolated Analog Output with Dual 6 A Relays

(4) Display Options select from:
Nothing(leave field blank) for Standard with Red LED Display
-GN for Green LED Display
Note: All combinations may not be valid, check spec sheet for valid part numbers.
