Low Range Constant Moment Beam Load Cells

LCM601 Series

LCM601 Load Cell Constant Moment Beam Type | LCM601 Series

LCM601 Load Cell Constant Moment Beam Type

470,00 LCM601-5

  • 5-Point NIST Traceable Calibration with 59 kOhm Shunt Cal Data Provided
  • 4-Direction Overload Stops
  • 0.25% Interchangeability for Scale Applications
  • High-Quality All Stainless Steel Construction
  • Rugged Industrial Design
Load Cells, Force Sensors and Torque Transducers - View related products

Description

OMEGA’s LCM601 Series comprises extremely low-capacity industrial load cells with built-in overload stops in all 4 directions for added durability. They offer high accuracy and rugged construction in a small package and are ideal for small scales and for industrial weighing applications.

The LCM601 is also available in standard configurations, with 0-1 to 0-25 lb ranges and standard threads. Please see the LC601 for complete details, or contact our Sales department for more information..

SPECIFICATIONS
Excitation: 10 Vdc, 15V max
Output: 2 mV/V ±0.25%
5-Point Calibration (in Compression): 0%, 50%, 100%, 50%, 0%
Linearity: ±0.03% FSO
Hysteresis: ±0.03% FSO
Repeatability: ±0.02% FSO
Zero Balance: ±1% FSO
Operating Temperature Range: -34 to 82°C (-30 to 180°F)
Compensated Temperature Range: 16 to 71°C (60 to 160°F)
Thermal Effects:
   Zero: ±0.0025% FSO/°F
   Span: ±0.0010% FSO/°F
Safe Overload: 150% of rated capacity
Ultimate Overload: 300% of capacity
Input Resistance: 360 Ω minimum
Output Resistance: 350 ±10 Ω
Full Scale Deflection: 0.005 to 0.015" typ
Construction: Stainless steel
Electrical Connections: 1.5 m (5') 4-conductor shielded color-coded cable
Place Order(Specify Model Number)
Part Number/Desc.
Qty
Description
Constant Moment Beam Load Cell with Four Way Overload Stops
Quick Ship
LCM601-1
470.00
Availability: 11 weeks

± 1 kgf (± 2.2 lb ) capacity
Quick Ship
LCM601-2
470.00
Availability: 1 week

± 2 kgf (± 4.4 lb) capacity
Quick Ship
LCM601-5
470.00
Availability: 11 weeks

± 5 kgf (± 11 lb) capacity
Quick Ship
LCM601-10
470.00
Availability: 11 weeks

± 10 kgf (± 22 lb) capacity
Accessories
Quick Ship
DP25B-S-230
€275.00
Availability: In Stock

4 Digit Load Cell Indicator with Excitation Voltage
Quick Ship
DP41-S-230
€590.00
Availability: In Stock

High Accuracy 6 Digit Load Cell Indicator with Excitation Voltage
Quick Ship
TXDIN1600S
€173.00
Availability: 7 weeks

Load cell amplifier with Excitation Voltage, DIN Rail Mounted
All amounts shown in EUR
Note: All LCM601 Series load cells include a 5 point NIST traceable calibration certificate.
