Aluminium S-Beam Load Cells, ±10 kgF to ±500 kgF

LCM105 and LCM115 Series

Aluminium S-Beam Load Cells, ±10 kgF to ±500 kgF | LCM105 and LCM115 Series

Aluminium S-Beam Load Cells, ±10 kgF to ±500 kgF

See All Models Below

  • Aluminium for Light Weight and Durability
  • Calibrated in Tension
  • 5-Point Calibration Certificate
Load Cells, Force Sensors and Torque Transducers - View related products

Description


SPECIFICATIONS
Excitation: 10 Vdc, 15 Vdc max
Output: 3 mV/V ±.0075 mV/V
Linearity: ±0.03% FSO
Hysteresis: ±0.02% FSO
Repeatability: ±0.01% FSO
Zero Balance: ±1% FSO
Operating Temp Range: -40 to 93°C (-40 to +200°F)
Compensated Temp Range: 17 to 71°C (60 to 160°F)
Thermal Effects: Zero: 0.002% FSO/°C Span: 0.002% Rdg/°C

Safe Overload: 150% of Capacity
Ultimate Overload: 300% of Capacity
Bridge Resistance: 350 ± 5 Ohms
Full Scale Deflection: 0.25 to 0.50 mm
Construction: Aluminium
Electrical:
  LCM105:
4 core screened cable
  LCM115: 6-pin connector. PT06F10-6S-R mating connector required



Place Order(Specify Model Number)
Part Number/Desc.
Qty
Description
LCM105 Cable Style
LCM105-10
Consult Sales
Availability:


Aluminium "S" beam load cell with ±10 kgF range
LCM105-25
Consult Sales
Availability:


Aluminium "S" beam load cell with ±25 kgF range
LCM105-50
Consult Sales
Availability:


Aluminium "S" beam load cell with ±50 kgF range
LCM105-100
Consult Sales
Availability:


Aluminium "S" beam load cell with ±100 kgF range
LCM105-250
Consult Sales
Availability:


Aluminium "S" beam load cell with ±250 kgF range
LCM105-500
434.09
Availability: 1 week

Aluminium "S" beam load cell with ±500 kgF range
LCM115 Connector Style
LCM115-250
Consult Sales
Availability:


Aluminium "S" beam load cell with ±250 kgF range. Requires Mating Connector
LCM115-500
Consult Sales
Availability:


Aluminium "S" beam load cell with ±500 kgF range. Requires Mating Connector
Accessories
PT06F10-6S-R
€33.49
Availability: In Stock

Mating Connector (RoHS compliant)
TXDIN1600S
221.19
Availability: In Stock

DIN Rail Mounted Signal Conditioner/Transmitter with Excitation & Remote Tare Input. 10-48 Vdc powered
All amounts shown in EUR
Note: LCM115 Connector style load cell only available from 250 kgF and up, See above table to order. Mating connector part number PT06F10-6S-R sold separately.
